Perforation Safety

You can set perforation safety to either of the following values:
Disabled (Default)
Enabled
To change or check the Perforation Safety value:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
5. Press ENTER to display the current value.
6. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for
7. Press ENTER.
8. Press START or RETURN to exit the Menu. See "Exiting the configuration

Jam Sensors

You can set Jam Sensors to either of the following values:
Enabled (Default)
Disabled
To change or check the Jam Sensors category:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
116
User's Guide
CONFIGURATION MENU
Printer Setup
Printer Setup
Perforation Safety
perforation safety is displayed.
An asterisk (*) will be displayed in front of the selected value.
menu" on page 39.
CONFIGURATION MENU
Printer Setup
The printhead is not parked all the way to the
right of the print line while the perforation of the
form is passing through the mylar opening.
The printhead is parked all the way to the right of
the print line so that the perforation of the form
can advance through the mylar without the
printhead touching the form.
Note: This setting is recommended for thick
multiple-part forms.
Enables the paper jam sensors on the front and
rear tractors. This setting alerts the operator with
an 002 FORMS JAMMED FRONT or 020 FORMS JAMMED
REAR message on the operator panel when a
jammed form is detected in one of the paper paths.
Disables the paper jam sensors. We recommend
that these sensors not be disabled.
