5. Press ENTER to display the current value.
6. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for
7. Press ENTER.
8. Press START or RETURN to exit the Menu. See "Exiting the configuration

Sensor Tune

This parameter establishes the black light threshold levels for all sensors. This
adjustment is set initially when the printer is manufactured and may have to be
adjusted for long-term aging of the sensor if false form jams occur or if unusual
ambient lighting conditions exist in the printer location.
Important: All paper must be removed from the tractors and all covers must be
Note: Sensor Tune is available only in the Operator Print Tests menu.
To tune the sensors:
1. Press TEST.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
5. Press ENTER. The printer displays the following:
6. Press ENTER. The printer will now tune the sensors. Once the sensors are
7. Press START or RETURN to exit the Menu. See "Exiting the configuration
Bidirectional Adjustment is displayed.
An asterisk (*) will be displayed in front of the selected value.
menu" on page 39.
installed and closed before selecting this parameter.
OPERATOR PRINT TESTS
Printer Adjustments
Printer Adjustments
Sensor Tune
Sensor Tune
Remove Forms Press ENTER
tuned, the printer displays
Sensor Tune
Sensor Tune Complete
Printer Adjustments
Sensor Tune
menu" on page 39.
Chapter 9. Printer Adjustments
125
