5. Press ENTER and the printer displays
LAN Interface
IP Address
6. Press ENTER to display the current value.
7. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for IP
Address is displayed.
8. Press ENTER.
An asterisk (*) will be displayed in front of the selected value.
9. Press START or RETURN to exit the Menu. See "Exiting the configuration
menu" on page 39.

Subnet Mask

You can set the Subnet Mask:
For example, 255.255.254.000 (Default)
These values set the Subnet Mask number. This number is represented by a
decimal notation. The decimal values are divided into four fields by periods. Each
field's values can range from 0 to 255.
To change or check the Subnet Mask:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
CONFIGURATION MENU
ASCII Configuration
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
ASCII Configuration
LAN Interface
5. Press ENTER and the printer displays
LAN Interface
Subnet Mask
6. Press ENTER to display the current value.
7. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for
Subnet Mask is displayed.
8. Press ENTER.
An asterisk (*) will be displayed in front of the selected value.
9. Press START or RETURN to exit the Menu. See "Exiting the configuration
menu" on page 39.
Chapter 7. ASCII Configuration
101
