Moving the printer to the final location

Do not plug in the printer power cord until instructed to do so.
1. Remove the plastic covering.
Figure 4. Lifting the printer
2. Using two persons, safely move the printer to the selected location (see
6
User's Guide
Keep the packing material in a safe place. It should be used if you need to
repack the printer for shipment.
CAUTION:
<2-82> The 4247 Model Z03 printer weighs 33 kg (73 lb). Two
persons are required to lift it.
CAUTION:
!
<2-83> The lifting handles are located forward of the center of
gravity. For good printer balance, each person should place
one hand in a gray lifting handle and the other hand under
the rear of the printer.
"Choosing a suitable location" on page 2).
