Default Gateway; Host Name - Compuprint Z03 User Manual

Default Gateway

You can set the Default Gateway:
These values set the Default Gateway address. This number is represented by a
decimal notation. The decimal values are divided into four fields by periods. Each
field's values can range from 0 to 255.
To change or check the Default Gateway:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
5. Press ENTER and the printer displays
6. Press ENTER to display the current value.
7. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for
8. Press ENTER.
9. Press START or RETURN to exit the Menu. See "Exiting the configuration

Host Name

You can set the Host Name to:
v 14 Chars (max)
v 4247_xxxxxx (Default)
The host is identified by a name in the NetBios protocol over TCP/IP. This
function allows you to create that host name using a 14-character string. The last
6-digits of the MAC address are xxxxxx.
To change or check the Host Name:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
102
User's Guide
For example, 000.000.000.000 (Default)
CONFIGURATION MENU
ASCII Configuration
ASCII Configuration
LAN Interface
LAN Interface
Default Gateway
Default Gateway is displayed.
An asterisk (*) will be displayed in front of the selected value.
menu" on page 39.
CONFIGURATION MENU
ASCII Configuration
