Figure 27. Aligning the form
10. Close the tractor area cover.
11. Press STOP to make the printer NOT READY.
12. Press LOAD/EJECT to feed the forms.

Printing the Quick Reference as a test page

The Quick Reference print test familiarizes you with the operator panel and
configuration menu while providing a check for printer operation and print
quality.
To perform the test:
1. Ensure that the printer is offline. If the printer is READY, press STOP to make
2. Press TEST.
3. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays:
20
User's Guide
7. To position the paper for the first column printing, move both tractors
aligning the left edge of the form with the 11
Note: Aligning the left-hand edge of the paper past the 22
printer cabinet will cause the paper to be misaligned with the Paper
Load Sensor resulting in a '001 End of Forms' error.
8. Position the right tractor so that the pins on both tractors are centered in the
pin holes on both edges of the form. The form should not be over tensioned,
nor should there be slack. The form should lie flat and even between the two
tractors.
9. While holding the left and the right tractors in place, lock both locking levers.
the printer NOT READY.
OPERATOR PRINT TESTS
Quick Reference
th
spacer on the printer base.
nd
spacer on the
