D D GPS-A symbol
Selects the desired GPS-A symbol.
Available symbols: Ambulance, Bus, Fire Truck, Bicycle,
Yacht, Helicopter, Small Aircraft, Ship
(Power Boat), Car
Balloon, Jeep, Recreational Vehicle,
Truck, Van, Other
If "Other" is selected, set the desired symbol code as follows;
q Push [MAIN•BAND] to enter programming condition.
w Rotate [DIAL] to select the 1st character from "\" and "/."
e Push [>](M/CALL•MW)
(Left band's)
r Rotate [DIAL] to select the 2nd digit character.
t Push [MAIN•BAND] to program the symbol code.
When "Other" is selected, check the symbol codes of
®
APRS, and set it correctly.
, Motorcycle,
(default)
to select the 2nd digit.

MENU SCREEN OPERATION

D D Comment
Program up to a 43-character* comment. The programmed
comment is transmitted with the GPS position data.
*36-character comment can
"COURSE/SPEED" is selected in data extension.
q Push [MAIN•BAND] twice to enter programming condition.
wRotate [DIAL] to select the desired character.
• Push [Aa](TONE•DTMF) to select the character group from cap-
ital letters or lower case letters.
• Push [1/](M/CALL•MW) (Right band's) to select the character
group from numbers or symbols.
• Push [>](M/CALL•MW) (Left band's) or [<](V/MHz•SCAN) (Left
band's) to move the cursor right or left, respectively.
• Push [CLR](DUP/MONI) to clear the selected character.
• Push and hold [CLR](DUP/MONI) for 1 sec. to clear all charac-
ters after the selected character.
eRepeat steps w until the desired comment is programmed.
r Push [MAIN•BAND] to set the programmed comment.
tPush [BACK](V/MHz•SCAN)
GPS-A set mode screen.
13
only be programmed when
to return to the
(Right band's)
