Specifications And Options; Specifications - Icom IC-E2820 Instruction Manual

■ Specifications
D D GENERAL
• Frequency coverage :
Version Left Band
Rx: 118–549.995*
1,
Europe1
Tx: 144–146, 430–440
Europe2 Tx/Rx: 144–146, 430–440
* 1 Guaranteed: 144–146 MHz range only.; *
• Type of emission : FM, AM
• Number of memory channels : 522 (incl. 20 scan edges and 2 calls)
• Frequency resolution : 5, 6.25, 10, 12.5, 15, 20, 25, 30, 50 kHz
• Operating temperature range : –10°C to +60°C
• Frequency stability : ±2.5 ppm
• Power supply requirement : 13.8 V DC ±15%
• Current drain :
(at 13.8 V DC: approx.)
Transmit
Receive
(simultaneous receive)
• Antenna connector : SO-239
• Dimensions :
(proj. not included)
Main Unit
Remote controller
• Weight :
(approx.)
Main unit
Remote controller

SPECIFICATIONS AND OPTIONS

(unit: MHz)
Right Band
Rx: 118–173.995* 1 , 375–549.995*
*
2
810–999.99* 3
Tx: 144–146, 430–440
2 Guaranteed: 430–440 MHz; * 3 Not guaranteed
,
(Receive only)
DV
(optional UT-123 is required)
(–10°C to +60°C)
at 50 W 13 A
standby 1.2 A
max. audio 1.8 A
(50 Ω) ×2 (Tx/Rx and Diversity)
150(W) × 40(H) × 187.7(D) mm
150(W) × 58(H) × 31.5(D) mm
1.5 kg
210 g
(incl. separation cable)
D D TRANSMITTER
• Modulation system
• Output power
• Max. frequency deviation
2 ,
• Spurious emissions
• Microphone connector
D D RECEIVER
• Receive system
• Intermediate frequencies
Left band
Right band
• Sensitivity
(amateur bands only)
FM
(12 dB SINAD)
DV
(BER 1%)
(optional UT-123 is required)
• Squelch sensitivity
†
(threshold)
• Selectivity † (typical)
Wide
Narrow
DV
(optional UT-123 is required)
• Spurious and image rejection
• AF output power †
(at 13.8 V DC)
• Ext. speaker connectors
All stated specifications are subject to change without notice or obligation.
: Variable reactance frequency modulation
: 50/15/5 W
(approx.)
: ±5.0 kHz
(wide)
±2.5 kHz
(narrow)
: Less than –60 dB
: 8-pin modular
(600 Ω)
: Double-conversion superheterodyne
:
1st: 38.85 MHz, 2nd: 450 kHz
1st: 46.35 MHz, 2nd: 450 kHz
:
Less than 0.18 µV
Less than 0.35 µV
: Less than 0.13 µV
:
More than 10 kHz/6 dB
Less than 30 kHz/60 dB
More than 6 kHz/6 dB
Less than 20 kHz/60 dB
More than 50 dB
† : More than 60 dB
*More than 55 dB for UHF on left band.
: More than 2.4 W
at 10% distortion with an
8 Ω load
: 3-conductor 3.5 (d) mm/8 Ω
† Guaranteed 144–146 MHz and 430–440 MHz ranges only.
