➥ During DV*
mode operation:
(Digital)
● "DSQL" appears while the digital call sign squelch
●
function is in use.
(p. 90)
● "CSQL" appears while the digital code squelch func-
●
tion is in use.
(p. 90)
➥ " " appears with the "TSQL," "DTCS," "DSQL"* or "C
SQL"* indicator while the pocket beep function is in use.
(pgs. 85, 90)
*Available only when the optional UT-123 is installed.
t EMR MODE INDICATOR
➥ "EMR" appears when the EMR mode* operation is in
use.
➥ "L" appears when packet loss occurs during the low-
speed data communication*.
*Available only when the optional UT-123 is installed.
y GPS INDICATOR
(p. 122)
➥ Appears while GPS function* is in use and GPS signal
is received..
➥ Blinks when GPS signal cannot be received.
*Available only when the optional UT-123 is installed.
u DTMF INDICATOR
(p. 82)
Appears while automatic DTMF transmission is in use.
i BREAK-IN INDICATOR
(p. 51)
Appears when the break-in* operation is in use.
*Available only when the optional UT-123 is installed.
(p. 56)
PANEL DESCRIPTION
o AUTO POWER OFF INDICATOR
Appears when the auto power OFF function is in use.
!0 KEY LOCK INDICATOR
(p. 19)
Appears when the key lock function is activated.
!1 FREQUENCY READOUT
Shows the operating frequency, set mode contents, etc.
• Frequency decimal point blinks while scanning. (p. 74)
!2 PRIORITY INDICATOR
(p. 80)
Appears while priority watch is activated, blinks while pri-
ority watch is paused.
!3 MEMORY CHANNEL NUMBER INDICATORS
➥ Shows the selected memory channel number.
➥ Shows the selected bank initial.
➥ "C" appears when the call channel is selected.
!4 SKIP INDICATOR
(p. 78)
➥ "≈" appears when the displayed memory channel is
specified as a skip channel.
➥ " P ≈" appears when the displayed frequency is specified
as a program skip frequency.
!5 MEMORY INDICATOR
(p. 60)
Appears when memory mode is selected.
