• Setting examle 2
Zone A
Area 1 Repeater 1
: A11111
Zone B
Area 5 Repeater 5
: B55555
❑ The setting when Station A is call-
ing Station C
UR : B6666C
R1 : A22222
R2 : A33333 G
MY : A2222A
DV MODE OPERATION (Optional UT-123 is required)
Area 2 Repeater 2
: A22222
Station A
: A2222A
Area 6 Repeater 6
: B66666
Station C
: B6666C
❑ The setting when Station A is mak-
ing a CQ call in area 8
UR : /B88888
R1 : A22222
R2 : A33333 G
MY : A2222A
Area 3 Repeater 3
(Gateway) : A33333
Station B
Internet Internet
: A3333B
network network
Area 7 Repeater 7
(Gateway) : B77777
❑ The setting when Station B is call-
ing Station C
UR
R1
R2
MY
Area 4 Repeater 4
: A44444
Area 8 Repeater 8
: B88888
: B6666C
: A33333 G
: NOT USE✱
: A3333B
