OSPF Interface Configuration

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, go to the OSPF Interfaces Configuration form. Select an interface number, or open
the OSPF Interfaces folder and click Add OSPF Interface.
The following table describes the OSPF Interface Configuration controls:
Table 150 OSPF Interface Configuration controls
Control
IP Interface Identifier (1-256)
Area Number (0-2)
Enabled?
Router Priority (0-255)
Output Cost (1-65535)
Hello Interval (1-65535 sec)
Dead Interval (1-65535 sec)
Transit Delay (1-3600 sec)
Retransmit Interval (1-3600 sec)
Authentication Key
MD5 Key ID (1-255)
Descriptions
Assigns a numeric identifier to the OSPF IP interface.
Defines the area index used by the interface.
Enables or disables the OSPF interface.
Displays the assigned priority value to the OSPF interfaces.
(A priority value of 127 is the highest and 1 is the lowest. A priority value of 0 specifies
that the interface cannot be used as Designated Router (DR) or Backup Designated Router
(BDR).)
Displays cost set for the selected path—preferred or backup. Usually the cost is inversely
proportional to the bandwidth of the interface. Low cost indicates high bandwidth.
Displays the interval in seconds between the
Displays the health parameters of a hello packet, which is set for an interval of seconds
before declaring a silent router to be down.
Displays the transit delay in seconds.
Displays the retransmit interval in seconds.
Sets the authentication key to clear the password.
Assigns an MD5 key to the interface.
packets for the interfaces.
hello
Configuring the switch 182
