The following table describes the Failure Detection Pair Configuration controls:
Table 176 Failure Detection Pair Configuration controls
Control
Enable/Disable FDP
LtM Ports Available
LtM Ports Selected
LtD Ports Available
LtD Ports Selected
LtM Trunks Available
LtM Trunks Selected
LtD Trunks Available
LtD Trunks Selected
Description
Enables or disables the Failover Pair.
Lists the ports that can be added to the Link to Monitor (LtM). Only uplink ports (20-24) are
allowed in the LtM.
Lists the ports that are members of the LtM.
Select a port number in the LtM Ports Available list and click Add to add the port to the
LtM.
Select a port number in the LtM Ports Selected list and click Remove to remove the port
from the LtM.
Lists the ports that can be added to the Link to Disable (LtD). Only downlink ports (1-16) are
allowed in the LtD.
Lists the ports that are members of the LtD.
Select a port number in the LtD Ports Available list and click Add to add the port to the LtD.
Select a port number in the LtD Ports Selected list and click Remove to remove the port from
the LtD.
Lists the trunk groups that can be added to the Link to Monitor (LtM). The LtM trunk group
can contain only uplink ports (20-24).
Lists the trunk groups that are members of the LtM.
Select a trunk group number in the LtM Trunks Available list and click Add to add the trunk
group to the LtM.
Select a trunk group number in the LtM Trunks Selected list and click Remove to remove the
trunk group from the LtM.
Lists the trunk groups that can be added to the Link to Disable (LtD). LtD trunk groups can
contain only downlink ports (1-16).
Lists the trunk groups that are members of the LtD.
Select a trunk group number in the LtD Trunks Available list and click Add to add the trunk
group to the LtD.
Select a trunk group number in the LtD Trunks Selected list and click Remove to remove the
trunk group from the LtD.
