OSPF Summary Ranges Configuration

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > OSPF Routing Protocol > OSPF Summary Ranges (click the
underlined text, not the folder).
This form provides a summary of the state of OSPF summary ranges.

OSPF Summary Range Configuration

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, go to the OSPF Summary Ranges Configuration form. Select a summary range
number, or open the OSPF Summary Ranges folder and click Add Summary Range.
The following table describes the OSPF Summary Range Configuration controls:
Table 148 OSPF Summary Range Configuration controls
Control
Range Number (1-16)
Enabled?
Hide Range
Area number (0-2)
IP Address
Descriptions
Assigns a numeric identifier to the OSPF summary range.
Enables or disables the OSPF summary range.
Hides or shows the OSPF summary range.
Defines the area index used by the switch.
Defines the base IP address for the range.
Configuring the switch 180
