Switch Ports Dashboard

To display the following form, select Switch Ports (click the underlined text, not the folder).
The following table describes the Switch Ports Dashboard controls:
Table 9 Switch Ports Dashboard controls
Control
Status
Switch Port Info
Operational Status
Speed/Duplex/Flow Ctl
Input Frames/Output Frames
Link State Changes/Total Errors
For more information, select a port number to display detailed statistics for that port.
Description
Shows if the port is enabled (green) or disabled (black).
Summarizes the following port information:
STP
: Shows if the port has Spanning Tree Protocol
rmon enabled
: Shows if RMON is
portfast: Shows if Port Fast Forwarding is
tagging
: Shows if this port has VLAN Tagging
PVID
: VLAN ID of any VLAN(s) to which this port is a member.
Displays the operational status of the port.
Displays parameters for the port link.
Displays the number of frames that have been received by this port (Input Frames) and
the number of frames that have been transmitted by this port (Output Frames).
Displays the total number of link state changes for this port and the total number of
errors logged by this port.
enabled disabled
or
disabled
or .
enabled disabled
or .
enabled disabled
or
.
.
Dashboard 24
