The following table describes the OSPF Virtual Link Configuration controls:
Table 151 OSPF Virtual Link Configuration controls
Control
Virtual Link Identifier (1-3)
Area Number (0-2)
Enabled?
Hello Interval (1-65535 sec)
Dead Interval (1-65535 sec)
Transmit Delay (1-3600 sec)
Retransmit Interval (1-3600 sec)
Virtual Neighbor Router ID
Authentication Key
MD5 Key ID (0-255)

OSPF Hosts Configuration

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > OSPF Routing Protocol > OSPF Hosts (click the underlined text, not
the folder).
Descriptions
Assigns a numeric identifier to the virtual link.
Defines the area index used by the virtual link.
Enables or disables the OSPF virtual link.
Displays the authentication parameters of a hello packet, which is set to be in an interval
of seconds.
Displays the health parameters of a hello packet, which is set to be in an interval of
seconds. Default is 40 seconds.
Displays the delay in transit in seconds. Default is one second.
Displays the retransmit interval in seconds. Default is five seconds.
Displays the router ID of the virtual neighbor. Default is 0.0.0.0
Displays the password (up to eight characters) for each virtual link. Default is
Sets MD5 key ID for each virtual link. Default is 0 (
none
none)
.
Configuring the switch 184
.
