VRRP General Configuration

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > Virtual Router Redundancy Protocol > General.
The following table describes the VRRP General Configuration controls:
Table 163 VRRP General Configuration controls
Control
VRRP Processing Enabled?
VRRP virtual router tracking
increment (0-254)
VRRP IP interface tracking
increment (0-254)
VRRP VLAN switch port tracking
increment (0-254)
Virtual Router Identifier (1-255)
IP interface (1-255)
Enabled?
Priority (1-254)
Advertisement Interval (1-255)
Descriptions
Globally enables or disables VRRP processing.
Defines the priority increment value (1 through 254) for virtual routers in master mode
detected on this switch. The default value is 2.
Defines the priority increment value (1 through 254) for active IP interfaces detected on
this switch. The default value is 2.
Defines the priority increment value (1 through 254) for active ports on the virtual router's
VLAN. The default value is 2.
VRRP Virtual Router Group Configuration
Assigns a numeric identifier to the virtual router group.
Defines the IP interface associated with the virtual router group.
Enables or disables the virtual router group.
Defines the election priority bias for this virtual router group. This can be any integer
between 1 and 254. The default value is 100.
During the master router election process, the routing device with the highest virtual router
priority number wins. If there is a tie, the device with the highest IP interface address
wins. If this virtual router's IP address (
interface, the priority for this virtual router will automatically be set to 255 (highest).
When priority tracking is used (
/cfg/l3/vrrp/vr #/track
to a number of performance and operational criteria.
Defines the time interval between VRRP master advertisements. This can be any integer
between 1 and 255 seconds. The default is 1.
) is the same as the one used by the IP
addr
/cfg/l3/vrrp/track or
), this base priority value can be modified according
Configuring the switch 195
