OSPF Virtual Links Dashboard

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > OSPF > Virtual Links (click the underlined text, not the folder).
The following table describes the OSPF Virtual Links Dashboard controls:
Table 37 OSPF Virtual Links Dashboard controls
Control
Virtual Link
Enabled?
Area Number
Neighbor Router ID
Transit Delay

RIP General Information

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > RIP > General.
The following table describes the Routing Information Protocol (RIP) General Information controls:
Table 38 RIP General Information controls
Control
Global RIP Enabled State
Update Period (sec)
Description
Displays the virtual link number.
Displays the status of the virtual link, either Enabled or Disabled.
Displays the area number associated with the virtual link.
Displays the neighbor router ID.
Displays the transit delay value, in seconds.
Description
Displays the global state of RIP: enabled or disabled.
Displays the time interval for sending for RIP table updates.
Dashboard 51
