Route Table Information
NOTE:
This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > Network Routes (click the underlined text, not the folder).
The following table describes the Route Table Information controls:
Table 26
Route Table Information controls
Control
Search Operation
Entry #
Destination
Description
To focus the search for an IP static route, enter search parameters:
Route Type
Route Tag
Routes for a Destination IP
Routes to a Gateway IP
Route for an IP Interface
Fields that have a value of "any" are ignored during the search.
Choose a search operation:
or: Search for network routes specified in the Search range that meet any
of the criteria entered.
and: Search for network routes specified in the Search range that meet all
of the criteria entered.
Click Search to display network routes that fit the range and meet the criteria
entered.
Displays the entry number for each route.
Displays the destination IP address fore the IP route.
