Table 170 Access Control List Configuration controls
Control
Ethernet Type
VLAN ID (1-4095)
802.1p Priority
Type of Service (0-255)
Protocol (0-255)
Source IP Address
Destination IP Address
TCP/UDP Src Port (1-65535)
TCP/UDP Dst Port (1-65535)
TCP Flags
Statistics
Egress Port
Description
Defines the Ethernet type for this ACL.
Defines a VLAN number and mask for this ACL.
Defines the 802.1p priority for the ACL.
Defines a Type of Service value for the ACL. For more information on ToS, see RFC 1340
and 1349.
Defines an IP protocol for the ACL. If defined, traffic from the specified protocol matches this
filter. Specify the protocol number. Listed below are some of the well-known protocols.
Number Name
1 icmp
2 igmp
6 tcp
17 udp
89 ospf
112 vrrp
Defines a source IP address for the ACL. If defined, traffic with this source IP address will
match this ACL. Specify an IP address in dotted decimal notation.
Defines a destination IP address for the ACL. If defined, traffic with this destination IP
address will match this ACL.
Defines a source port for the ACL. If defined, traffic with the specified TCP or UDP source
port will match this ACL. Specify the port number. Listed below are some of the well-known
ports:
Number Name
20
ftp-data
21 ftp
22 ssh
23 telnet
25
smtp
37
time
42
name
43 whois
53 domain
69 tftp
70
gopher
79
finger
80
http
Defines a destination port for the ACL. If defined, traffic with the specified TCP or UDP
destination port will match this ACL. Specify the port number, just as with
Defines a TCP/UDP flag for the ACL.
Enables or disables the statistics collection for the ACL.
Selects an egress port to add to the ACL.
The egress port ACL will not match a Layer 2 broadcast or multicast packet. The egress port
ACL will not match packets if the destination port is a trunk.
above.
sport
