RIP Interfaces Dashboard

NOTE: This form is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
To display the following form, select Layer 3 > RIP > RIP Interfaces (click the underlined text, not the folder).
The following table describes the RIP Interfaces Dashboard controls:
Table 39 RIP Interfaces Dashboard controls
Control
Search Range
Search Options
Interface ID
RIP State
RIP Version
Default Action
Supply Updates
Listen to Updates
Poisoned Reverse
Triggered Updates
Multicast Updates
Metric
Auth Type
Description
To search for a RIP interface, enter a range of interface ID numbers in the
From and To fields.
To focus the search for a RIP interface, enter optional search parameters:
RIP version
RIP state
Fields that have a value of "any" are ignored during the search.
Choose a search operation:
or: Search for RIP interfaces specified in the search range that meet any
of the criteria entered.
and: Search for RIP interfaces specified in the search range that meet all
of the criteria entered.
Click Search to display RIP interface that fit the range and meet the criteria
entered.
Displays each interface number.
Displays the current status of RIP in the interface: enabled or disabled.
Displays the RIP version used by the interface.
Displays the default action for RIP on the interface.
Displays the current status of Supply: enabled or disabled.
Displays whether Supply Updates is enabled or disabled.
Displays whether Poisoned Reverse is enabled or disabled.
Displays whether Triggered Updates is enabled or disabled.
Displays whether Multicast Updates is enabled or disabled.
Displays the route metric for the interface.
Displays the authentication type for the interface.
