Chapter 13
WARNING
To prevent the rack from rolling while you mount the HP
NetServer, ensure the leveler screws on the rack's lower four
corners are in firm contact with the floor.
3. With the help of at least one other person, lift the HP NetServer by its four
handles.
4. Move the HP NetServer between the extended slide members to position
the slides underneath the HP NetServer's handles on each side. See Figure
13-8.
2. Secure NetServer
to slides with
screws.
Figure 13-8. Mounting the Server on the Slides
5. Lower the HP NetServer onto the slide members.
The HP NetServer's handles will support the HP NetServer on its slides,
temporarily.
6. Adjust the HP NetServer's position on the slides to line up the mounting
holes on the side of the chassis with the screw holes in the slide members.
Alternative Rack Mounting
1. Move NetServer onto slides.
159
