smartLink HW-DP - User Guide
2.4 Technical data
Hardware
Interfaces
Supported communication
protocols
Supported PROFIBUS remote IOs
Supported HART IP IO modules
Supported HART-IP Applications
Supported FDT Applications
Dimensions (H x W x D) Weight
8
Processor: Intel Cyclone V SoC with dual core ARM Cortex-A9
Status LEDs: PWR, RUN, ERR, BUS
Real-Time Clock: Real-time clock with buffering, setting time via browser or
by NTP server
Ethernet: 1 xIEEE 802.3 10BASE-T, 100Base-TX, 1000Base-T, connector RJ4
PROFIBUS DP: 1 segment with RS485 physical layer, connector 90-pin sub-
D socket
HART IP, PROFIBUS DP, FDI Communication Server (OPC UA)
Siemens:
T 200SP: 155-6BU01-0CN0
ET 200iSP: 152-1AA00-0AB0
ET 200M: 153-2BA10-0XB0
ABB:
S800: CI801, CI840, CI840A
S900: CI920N, CI920S
Pepperl+Fuchs:
LB: LB8105, LB8106, LB8109
FB: FB8206, FB8209
R.Stahl:
iS1+: CPM 9440/15-01-11
Turck:
BL20: BL20-E-GW-DP, BL20-GW-DPV1
excom: GDP 1.5
WAGO:
I/O System 750: 750-333, 750-833
Siemens:
ET 200SP: 134-6TD00-0CA1, 135-6TD00-0CA1
ET 200iSP: 134-7TD00-0AB0, 135-7TD00-0AB0, 134-7TD50-0AB0, 138-
7FA00-0AB0
ET 200M: 332-8TF01-0AB0, 331-7TF00-0AB0, 331-7TF01-0AB0, 331-7TB00-
0AB0, 332-8TF00-0AB0
ABB:
S800: AI815, AO815, AI845, AO845A, AI895, AO895
S900: AI930N, AO930N
Pepperl+Fuchs:
LB: LB3002, LB3102, LB3103, LB3105, LB4002, LB4005, LB4102, LB4105,
LB3005A2, LB3006A, LB3106A, LB4106A, LB7104A FB: FB3202B1, FB3202B2,
FB3205B2, FB3205B3, FB3302B2, FB3305B2, FB4202B2, FB4202B3,
FB4205B2, FB4205B3, FB4205C2, FB4302B2, FB7204B3, FB7304B3
R.Stahl:
iS1+: AIM 9461/12-08-11, AOM 9466/12-08-11, AUM 9468/32-08-11
Turck:
BL20: BL20-2AIH-I, BL20-2AOH-I
excom: AIH40Ex, AOH40Ex
WAGO:
I/O System 750: 750-484, 75x-842
Emerson AMS Device Manager V14.1.1, V14.5
Endress + Hauser Netilion (FieldEdge SGC500)
ABB FIM V3.01
PACTware, Endress + Hauser FieldCare
120 mm x 28 mm x 110 mm
