smartLink HW-DP - User Guide
4.5.3 Managing projects
This chapter describes how you can create a new project or import an existing network management
project in FIM for the connected smartLink HW-DP.
4.5.3.1
Creating a project
1. Click the burger icon
2. Select the PROJECTS menu to create a project.
3. Click the plus icon
The New Project window appears.
4. Enter a Name and a Description in the top two rows.
5. Tick the checkbox for Thorsis HART-IP FDI Communication Server and enter the localhost,
computer name or the IP address of the server in the IP ADDRESS field.
6. Click [ADD] to continue. A NEW PROJECT window appears. In this window, the result and
message line next to your project name shows if the project has been added successfully.
7. Click [OK] to continue.
The Project Management window appear displaying all existing projects.
72
in the top left corner.
at the top of the window.
Version EN-012025-1.32
