smartLink HW-DP - User Guide
4.2.1.3
AMS Device Manager
1. Click Windows Start
The AMS device manager window opens.
2. Right-click your smartLink HW-DP and select Rebuild Hierarchy.
3. Right-click a Station and select Scan
HART IO module.
62
à
AMS Device Manager
Note
The PROFIBUS slaves are displayed in AMS DM as Station X where X corresponds to
the PROFIBUS address of the PROFIBUS slave. The HART IO modules of the PROFIBUS
slaves are displayed in AMS as HART Card X where X corresponds to the slot number
of the HART IO module.
à
AMS Device Manager.
à
All Devices see all the HART devices connected to this
