4.1.6 HART IP
4.1.6.1
Settings
1. Select HART IP
2. Enter an alternate port number if required. The communication is typically run on the default port
5094. Set the alternate port to use a different port if the default port is already occupied by
another protocol.
3. Tick the checkbox for Add Remote IOs to Network Topology to start the PROFIBUS slave hosting
the Remote IO .
4. Tick the checkbox Segment DP1 to start the HART IP server.
5. Click [Apply] to confirm and activate your settings.
4.1.6.2
Log
Select HART IP
used by Softing support for troubleshooting a problem.
Version EN-012025-1.32
à
Settings to see the current settings.
à
Log to see details of the HART IP communication activity. This log file is typically
