About smartLink HW-DP
2
The Softing smartLink HW-DP provides access to the communication system and connects the higher-
level network structure with the field level.
The default configuration allows for a start-up in only a few minutes. In order to prevent network
disruptions by unauthorized configuration changes, all configuration functions are protected by user
administration.
2.1 Intended use
The smartLink HW-DP is designed to be used as a secure access point to PROFIBUS networks. Any other
use is deemed non-intended use.
2.2 Supported features
smartLink HW-DP supports the following features:
§
parameter setting of HART devices connected to PROFIBUS DP networks via HART IP and FDT/DTM
§
parameter setting of PROFIBUS DP devices via FDT/DTM
§
provides process data, asset and diagnostic information of PROFIBUS devices via OPC UA
§
provides asset and diagnostic information of PROFIBUS devices for Softing's plantPerfect Monitor
2.3 System requirements
To parametrize PROFIBUS and HART devices with your smartLink HW-DP you will need:
§
24V power supply
§
PC with web browser
§
Ethernet cable
§
PROFIBUS cable
Version EN-012025-1.32
CAUTION
Do not use this device in hazardous areas! See Section
ambient conditions.
Note
Installation and operation of the smartLink HW-DP must be performed by qualified
personnel only.
Chapter 2 - About smartLink HW-DP
8
Technical Data for permissible
