Softing smartLink HW-DP User Manual page 37

4.1.3.6
Time & Date
Select Settings
HW-DP.
1. Click [Set time from browser] to synchronize the device with the PC date and time manually.
2. Click [Use time server] and enter the IP address of your time server to synchronize date and time
automatically.
Parameter
Browser time (UTC)
Device time (UTC)
NTP server
Time server
Version EN-012025-1.32
à
Time & Date in the side bar navigation to set the time and date of your smartLink
Meaning
The time set on the PC.
The time set on the smartLink HW-DP when you select [Set time
from browser]. The device time cannot be set separately.
IP address of a Network Time Protocol (NTP) server used for time
synchronization.
The time can be set either manually or using a time server.
Chapter 4 - Working with smartLink HW-DP
37
