HART table headers explained
Column Header
Channel
Long Tag / Message For HART devices with HART revision 6 and later, the Long Tag contained in the device is
Vendor
Device Type
HART Revision
Device Revision
HART Long Address The unique long address of the HART device.
Status
PROFIBUS table headers explained
Column Header
Address
Tag Function
Tag Location
Vendor
Device Type
HW Revision
SW Revision
Status
Version EN-012025-1.32
Meaning
Wiring position on which the HART device is connected to the module. Values are in the
range 0 .. <number of module channels > - 1
shown. For HART devices with HART revision 5 and earlier, the Message contained in the
device is shown.
This column displays in brackets the Manufacturer Identification code as a hexadecimal
value. A vendor name is shown if this value can be resolved.
This column displays in brackets the type of the HART device as a hexadecimal value. A
device type name is shown if this value can be resolved.
The HART protocol Major Revision number.
This column displays in brackets the type of the HART device as a hexadecimal value. A
device type name is shown if the value can be resolved.
Licensing state of HART device.
Meaning
Displays the address of the PROFIBUS device.
Displays the Tag Function contained in the device.
Displays the Tag Location contained in the device.
This column displays in brackets the manufacturer Identification code as a hexadecimal
value. A vendor name is shown only if this value can be resolved.
Displays the type of the PROFINET device as a hexadecimal value in brackets. A device
type name is shown if this value can be resolved.
Displays the hardware revision of the PROFINET device.
Displays the software revision of the PROFINET device.
It is either shown as "OK" (when a PROFINET device has been successfully scanned) or
with a red error text describing the error detected during the scan process.
Chapter 4 - Working with smartLink HW-DP
47
