7. Tick the Activate the Server... checkbox.
8. Click [Send] and wait until the status field shows connected.
9. Click [Close].
Establishing a connection to smartLink HW-DP as a HART-IP server
1. Click the ellipsis icon
A new widget appears.
2. Select the option Hardware Scan
or Scan on all levels (if you are using only one HART-IP server).
When the scan is completed successfully (see the progress bar at the bottom of the screen),the
smartLink HW-DP HART-IP server (or multiple servers where available) is shown in the FIM
Topology View. The connected HART-IP server is now communicating with the FIM client.
Version EN-012025-1.32
Note
If you are using an alternate port number for the HART-IP server, make sure to use the
correct number.
in the Thorsis HART-IP FDI Communication Server device tile.
à
Scan On this Level (if you have more than one HART-IP server)
