2.7 LED status indicators
smartLink HW-DP has four device status LEDs and two RJ45 connection status LEDs on the front:
PWR
RUN
ERR
BUS
The device status LEDs are permanently on or flash in different colors and frequencies as indicated
below:
Symbol
The RJ45 status LEDs indicate the following behaviour:
web server port LEDS
Version EN-012025-1.32
= power supply - refer to
= running - refer to
= error - refer to
= configuration - displays configuration upload - refer to
Color
none
red
green
red
red
green
green
green
orange (red/green)
orange (red/green)
Colour Behaviour
green
yellow
next section
12
next section
12
next section
Lighting
off
permanent
permanent
flashing (1 Hz)
flashing quickly (5 Hz)
flashing (1 Hz)
flashing slowly (0.5 Hz)
flashing quickly (5 Hz)
permanent
green permanent + red flashing (1 Hz)
ON when port has an active link
FLASHING when there is traffic on the port
Chapter 2 - About smartLink HW-DP
12
next section
12
