Maximum ambient
temperature (T
horizontal
3.1.6 Connecting to the network
1. Connect your PROFIBUS network to the RS485 port of your smartLink HW-DP.
2. Connect your PC running the asset management and network monitoring applications using the
Ethernet port.
WARNING
Installing smartLink HW-DP while your network is in operation may cause data transfer
problems if the network is in a poor electrical condition.
3.1.7 Powering up the device
Turn on the power supply. The boot process will take about 30 seconds. Refer to
11
indicators
Version EN-012025-1.32
)
a
vertical
for a detailed description of the LEDs and there behaviour.
T - no distance
a
60 °C
50 °C
Chapter 3 - Installation
T at 28mm distance
a
between devices
65 °C
60 °C
LED status
