smartLink HW-DP - User Guide
2.7.1 Status LEDs startup phase
LEDs
PWR RUN
PWR RUN
PWR RUN
PWR RUN
2.7.2 Status LEDs – factory mode
LEDs
PWR RUN
PWR RUN
PWR RUN
PWR RUN
PWR RUN
PWR RUN
12
ERR BUS
ERR BUS
ERR BUS
ERR BUS
Meaning
Device running in factory mode.
ERR BUS
Firmware update is running.
ERR BUS
Request to execute factory reset.
ERR BUS
Device executes factory reset.
ERR BUS
Software error - reboot the device.
ERR BUS
n.a
Software error - device restarted automatically and error is reported
ERR BUS
in log file.
n.a
Meaning
Power Off – check Power supply.
Power On - 24V DC power supply is ok.
Start up phase (up to 30 seconds).
Start up phase finished – check execution mode (normal or factory).
Version EN-012025-1.32
