Diskette Drive Cabling

The following procedure explains how to cable a diskette
drive.
1. Connect the diskette drive signal cable connector to the
signal connector on the diskette drive.
2. Locate an available power connector coming from the
power supply.
3. Connect the power cable to the power connector on the
device.

PC Card Adapter Cabling

The following procedure describes how to cable a PC card
adapter.
1. Connect the connectors at one end of the cable set to the
PC adapter board. (The PC adapter board is installed in
one of the expansion slots. See "Installing an Expansion
Board" if the board must be installed first.)
The connectors are keyed to fit only one way.
2. Connect the connectors at the other end of the cable set to
the connectors at the rear of the PC card adapter.
4-52 Installing Options
