System Board Jumper Summary

Jumper Function
A BMC Forced
Update Mode
B Chassis Intrusion
Detection
C FRB Timer Enable
D Boot Block Write
Protect
E Recovery Boot
F Password Clear
Pins (default in What it does at system
bold) reset
9-10 System boots normally.
10-11 System tries to boot BMC
firmware.
5-6, Enable Switch installed on chassis
indicates when cover has
been removed.
6-7, Disable Chassis intrusion switch is
bypassed.
1-2, Enable FRB operation is enabled
(system boots from
processor 1 if processor 0
fails).
2-3, Disable FRB is disabled.
13-14, Protect BIOS boot block is write-
protected.
14-15, BIOS boot block is
Erase/Program erasable and
programmable.
9-10, Normal System attempts to boot
using the BIOS stored in
flash memory.
10-11, Recovery BIOS attempts a recovery
boot, loading BIOS code
from a diskette into the
flash device. This is
typically used when the
BIOS code has been
corrupted.
5-6, Protect Maintains the current
system password.
6-7, Erase Clears the password.
Configuring the System 3-41
