Turn off and unplug the workstation before
connecting any cables to the back of the
workstation. Equipment may be damaged if you
connect cables while the power is on. Plug in the
power cable only after all other device cables
have been connected.
A – Mouse Port B – Keyboard Port C – COM1 Port D – Printer Port
E – COM2 Port F – VGA Monitor Connector G – Security Slot
H – Locking Tab I – USB Ports J – Audio Connectors
2-6 Setting Up the System
! CAUTION
Rear panel connectors
