IDE Connector Configuration
Configuration
1 device (hard drive)
2 devices (hard drive,
CD-ROM)
2 devices (hard drive, tape
backup)
2 devices (hard drive,
Zip drive)
3 devices (hard drive,
CD-ROM, Zip drive)
3 devices (hard drive,
CD-ROM, tape backup)
3 devices (hard drive, hard
drive, CD-ROM)
3 devices (hard drive, hard
drive, tape backup)
3 devices (hard drive, hard
drive, Zip drive)
4 devices (hard drive,
CD-ROM, Zip drive, tape
backup)
4 devices (hard drive, hard
drive, CD-ROM, tape backup)
4 devices (hard drive, hard
drive, CD-ROM, Zip drive)
4 devices (hard drive, hard
drive, Zip drive, tape backup)
Primary connector Secondary connector
Master - hard drive Master - none
Slave - none Slave - none
Master - hard drive Master - CD-ROM
Slave - none Slave - none
Master - hard drive Master - tape backup
Slave - none Slave - none
Master - hard drive Master - Zip drive
Slave - none Slave - none
Master - hard drive Master - CD-ROM
Slave - none Slave - Zip drive
Master - hard drive Master - CD-ROM
Slave - none Slave - tape backup
Master - hard drive Master - CD-ROM
Slave - hard drive Slave - none
Master - hard drive Master - tape backup
Slave - hard drive Slave - none
Master - hard drive Master - Zip drive
Slave - hard drive Slave - none
Master - hard drive Master - CD-ROM
Slave - Zip drive Slave - tape backup
Master - hard drive Master - CD-ROM
Slave - hard drive Slave - tape backup
Master - hard drive Master - CD-ROM
Slave - hard drive Slave - Zip drive
Master - hard drive Master - Zip drive
Slave - hard drive Slave - tape backup
Installing Options 4-43
