PC Setup
Word(s) Bit(s)
DM 6553 00 to 07
(port 2)
DM 6558 08 to 11
(port 1)
12 to 15
DM 6554 00 to 07
(port 2)
DM 6559 08 to 15
(port 1)
1-1-3

PC Setup Settings

Word(s) Bit(s)
Startup Processing (DM 6600 to DM 6614)
The following settings are effective after transfer to the PC only after the PC is restarted.
DM 6600 00 to 07
08 to 15
DM 6601 00 to 07
08 to 11
12 to 15
DM 6602 to 00 to 15
DM 6603
DM 6604 to 00 to 15
DM 6610
DM 6611 to 00 to 15
DM 6612
DM 6613 00 to 15
DM 6614 00 to 15
Pulse Output and Cycle Time Settings (DM 6615 to DM 6619)
The following settings are effective after transfer to the PC the next time operation is started.
DM 6615 00 to 07
08 to 15
4
Node Number (Host Link)
00 to 31 (BCD)
Start Code Enable (No-protocol)
0: Disable; 1: Set
End Code Enable (No-protocol)
0: Disable (number of bytes received)
1: Set (specified end code)
2: CR, LF
Start Code (No-protocol)
00 to FF (hexadecimal)
When bits 12 to 15 of DM 6553 or DM 6558 are set to 0:
Number of Bytes Received
00: Default setting (256 bytes)
01 to FF: 1 to 255 bytes
When bits 12 to 15 of DM 6553 or DM 6558 are set to 1:
End Code (No-protocol)
00 to FF (hexadecimal)
The following table shows the PC Setup settings in order in the DM area. For
details, refer to the page numbers shown.
Startup Mode (effective when bits 08 to 15 are set to 02).
00: PROGRAM; 01: MONITOR 02: RUN
Startup Mode Designation
00: Depends on CPU Unit DIP switch pin 7 and Programming Console switch settings
01: Continue operating mode last used before power was turned OFF
02: Setting in DM 6600 bits 00 to 07
Not used.
I/O Hold Bit Status (SR 25212)
0: Reset; 1: Maintain
Forced Status Hold Bit Status (SR 25211)
0: Reset; 1: Maintain
Inner Board Slot 1 Settings (See 1-2 Inner Board Settings for details.)
Not used.
Inner Board Slot 2 Settings (See 1-2 Inner Board Settings for details.)
Servicing Time Setting for Serial Communications Board Port 2
Servicing Time Setting For Serial Communications Board Port 1
Word for Pulse Output
00: IR 100; 01: IR101; 02: IR 102... 15: IR 115
Sets the word used for pulse output from an output on a Transistor Output Unit. Pulses
can be output only from one output at a time.
Not used. Set to 00.
Function
Function
Section 1-1
Page
12
13
9
9
9
46
