IR Area
Pulse I/O Board Flags/Bits
Word Bits
IR 232 00 to 15 High-speed Counter 1 PV (rightmost 4 digits)
IR 233 00 to 15 High-speed Counter 1 PV (leftmost 4 digits)
IR 234 00 to 15 High-speed Counter 2 PV (rightmost 4 digits)
IR 235 00 to 15 High-speed Counter 2 PV (leftmost 4 digits)
IR 236 00 to 15 Port 1 Pulse Output PV (rightmost 4 digits)
IR 237 00 to 15 Port 1 Pulse Output PV (leftmost 4 digits)
IR 238 00 to 15 Port 2 Pulse Output PV (rightmost 4 digits)
IR 239 00 to 15 Port 2 Pulse Output PV (leftmost 4 digits)
IR 240 to IR 243 00 to 15 Not used.
Absolute Encoder Interface Board Flags/Bits
Word Bits
IR 232 00 to 15 Absolute Encoder High-speed Counter 1 PV (rightmost 4 digits)
IR 233 00 to 15 Absolute Encoder High-speed Counter 1 PV (leftmost 4 digits)
IR 234 00 to 15 Absolute Encoder High-speed Counter 2 PV (rightmost 4 digits)
IR 235 00 to 15 Absolute Encoder High-speed Counter 2 PV (leftmost 4 digits)
IR 236 to IR 243 00 to 15 Not used.
Analog I/O Board Flags/Bits
Word Bits
IR 232 00 to 15 Analog Input 1 Conversion Value
IR 233 00 to 15 Analog Input 2 Conversion Value
IR 234 00 to 15 Analog Input 3 Conversion Value
IR 235 00 to 15 Analog Input 4 Conversion Value
IR 236 00 to 15 Analog Output 1 SV
IR 237 00 to 15 Analog Output 2 SV
IR 238 to IR 243 00 to 15 Not used.
Analog Setting Board (Slot 1 and 2) Flags/Bits
Word Bits
IR 220 00 to 15 Analog SV 1: 0000 to 0200 (4-digit BCD)
IR 221 00 to 15 Analog SV 2: 0000 to 0200 (4-digit BCD)
IR 222 00 to 15 Analog SV 3: 0000 to 0200 (4-digit BCD)
IR 223 00 to 15 Analog SV 4: 0000 to 0200 (4-digit BCD)
3-2-6

Flags/Bits for Communications Units

Controller Link Status
Area 1 (IR 090 to IR 095)
Word Bits
IR 090 00 to 14
15
IR 091 00 to 07
08 to 15
IR 092 00 to 07
08 to 15
IR 093 00 to 07
08 to 15
Function
Function
Function
Function
Function
Always 0
Local Node's Data Link Participation Status
0: The local node not in the Data Link or Data Link is
stopped.
1: The local node is participating in the Data Link.
Data Link Status: Node 1
Data Link Status: Node 2
Data Link Status: Node 3
Data Link Status: Node 4
Data Link Status: Node 5
Data Link Status: Node 6
Section 3-2
Read/
Write
R
R
R
R
R
R
R
R
---
Read/
Write
R
R
R
R
---
Read/
Write
R
R
R
R
W
W
---
Read/
Write
R
R
R
R
159
