Omron CQM1H - PROGRAM Programming Manual page 515

Cycle Time
Code Mnemonic ON execution
time (µs)
–– HMS 73.9
114.3
–– LINE 72.8
127.6
–– LOG 552.0
586.0
–– MAX 44.8
1.93 ms
–– MBS 46.2
48.6
104.0
–– MBSL 73.2
128.4
–– MIN 44.8
1.33 ms
–– NEG 33.7
36.1
72.3
–– NEGL 41.1
80.1
–– PID 1.59 ms
1.73 ms
458.5
673.0
–– PLS2 619.0
639.8
–– PMCR 182.0
728.0
772.0
–– PWM 202.8
207.4
223.1
–– RAD 106.0
140.4
–– SBBL 59.3
116.7
–– SCL2 81.5
137.6
–– SCL3 86.7
142.8
–– SEC 72.4
112.4
–– SIN 716.0
750.0
–– SQRT 206.0
490
Conditions
Word → word
*DM → *DM
Word → word
*DM → *DM
Word → word
*DM → *DM
Searching word, results to word
Searching 999 words via *DM, results to *DM
Constant × word → word
Word × word → word
*DM × *DM → *DM
Word × word → word
*DM × *DM → *DM
Searching word, results to word
Searching 999 words via *DM, results to *DM
Converting a constant → word
Converting a word → word
Converting *DM → *DM
Converting a constant → words
Converting *DM → *DM
Word → word (initial execution)
*DM → *DM (initial execution)
Word → word (when sampling)
*DM → *DM (when sampling)
Words for control words
*DM for control words
Constant for port/sequence number, DM for I/O word
*DM for port/sequence number, *DM for I/O word
*DM for port/sequence number, *DM for I/O word
Duty ratio specified by constant
Duty ratio specified by word
Duty ratio specified by *DM
Word → word
*DM → *DM
Word – word → word
*DM – *DM → *DM
Word → word conversion, words for parameter words
*DM → *DM conversion, *DM for parameter words
Word → word conversion, words for parameter words
*DM → *DM conversion, *DM for parameter words
Word → word
*DM → *DM
Word → word
*DM → *DM
Word → word
*DM → *DM
Section 7-3
OFF execution
time (µs)
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
