Multiple Forced Set/Reset –– Fk - Omron CQM1H - PROGRAM Programming Manual

Host Link Commands
Name
OP1 OP2 OP3 OP4
C I O (Space) IR or SR
L R (Space) (Space) LR
H R (Space) (Space) HR
A R (Space) (Space) AR
T I M (Space) Completion Flag (timer)
T I M H
T T I M
C N T (Space) Completion Flag (counter)
C N T R
6-5-28 MULTIPLE FORCED SET/RESET –– FK
Command Format
1 0
@ x 10 x 10 F
Node Header
No. code
Response Format
Parameters
Name
OP1 OP2 OP3 OP4
C I O (Space) IR or SR
L R (Space) (Space) LR
H R (Space) (Space) HR
A R (Space) (Space) AR
T I M (Space) Completion Flag (timer)
T I M H
T T I M
C N T (Space) Completion Flag (counter)
C N T R
466
Classification
Completion Flag (high-speed timer)
Completion Flag (totalizing timer)
Completion Flag (reversible counter)
Note The area specified under "Name" must be in four characters. Add spaces
after the data area name if it is shorter than four characters.
Force sets, force resets, or cancels the status of the bits in one word in the IR,
SR, LR, HR, AR, or TC area.
K OP1 OP2 OP3 OP4
Name
0 0
x 16 x 16
15 14
Bit
An end code of 00 indicates normal completion.
@ x 10
Node
No.
Name, Word address (Command)
In "Name," specify the area (i.e., IR, SR, LR, HR, AR, or TC) that is to be
forced set or reset. Specify the name in four characters. In "Word address,"
specify the address of the word that is to be forced set or reset.
Classification
Completion Flag (high-speed timer)
Completion Flag (totalizing timer)
Completion Flag (reversible counter)
Word address setting range
0000 to 0252
0000 to 0063
0000 to 0099
0000 to 0027
0000 to 0511
3 2 1 0
x 10 x 10 x 10 x 10
Word
address
Forced set/reset/cancel data
0 0 0 0
x 16 x 16 x 16 x 16
13 12 11 10
1 0 1
x 10 F K x 16
Header End code
code
Word address setting range
0000 to 0252
0000 to 0063
0000 to 0099
0000 to 0027
0000 to 0511
Section 6-5
0 0
x 16 x 16
FCS Terminator
1 0
↵
*
0
x 16
FCS Terminator
Bits
00 to 15
(decimal)
Always 00
↵
*
Bits
00 to 15
Always 15
