Omron CQM1H - PROGRAM Programming Manual page 186

SR Area
Word Bit(s)
SR248 00 to 15 Input Interrupt 0 Counter Mode PV Minus One
Counter PV-1 when input interrupt 0 is used in Counter Mode (4-digit hexadecimal).
SR249 00 to 15 Input Interrupt 1 Counter Mode PV Minus One
Counter PV-1 when input interrupt 1 is used in Counter Mode (4-digit hexadecimal).
SR250 00 to 15 Input Interrupt 2 Counter Mode PV Minus One
Counter PV-1 when input interrupt 2 is used in Counter Mode (4-digit hexadecimal).
SR251 00 to 15 Input Interrupt 3 Counter Mode PV Minus One
Counter PV-1 when input interrupt 3 is used in Counter Mode (4-digit hexadecimal).
SR252 00 High-speed Counter 0 Reset Bit
01 Control Bit for Inner Board in Slot 2
Pulse I/O Board: High-speed Counter 1 Reset Bit
Turn ON to reset PV of high-speed counter 1 (port 1).
Absolute Encoder Interface Board:
Absolute High-speed Counter 1 Origin Compensation Bit
Turn ON to set origin compensation for absolute high-speed counter 1 (port 1). Automat-
ically turns OFF when compensation value is set in DM 6611.
02 Control Bit for Inner Board in Slot 2
Pulse I/O Board: High-speed Counter 2 Reset Bit
Turn ON to reset PV of high-speed counter 2 (port 2).
Absolute Encoder Interface Board:
Absolute High-speed Counter 2 Origin Compensation Bit
Turn ON to set origin compensation for absolute high-speed counter 2 (port 2). Automat-
ically turns OFF when compensation value is set in DM 6612.
03 to 07 Not used.
08 Peripheral Port Reset Bit
Turn ON to reset peripheral port. (Not valid when Programming Device is connected.)
Automatically turns OFF when reset is complete.
09 RS-232C Port Reset Bit
Turn ON to reset RS-232C port. Automatically turns OFF when reset is complete.
10 PC Setup Reset Bit
Turn ON to initialize PC Setup (DM 6600 through DM 6655). Automatically turns OFF
again when reset is complete. Only effective if the PC is in PROGRAM mode.
11 Forced Status Hold Bit
OFF: Bits that are forced set/reset are cleared when switching from PROGRAM mode to
ON: The status of bits that are forced set/reset are maintained when switching from
12 I/O Hold Bit
OFF: IR and LR bits are reset when starting or stopping operation.
ON:
13 Not used.
14 Error Log Reset Bit
Turn ON to clear error log. Automatically turns OFF again when operation is complete.
15 Output OFF Bit
OFF: Normal output status.
ON:
SR253 00 to 07 FAL Error Code
The error code (a 2-digit number) is stored here when an error occurs. The FAL number
is stored here when FAL(06) or FALS(07) is executed. This byte is reset (to 00) by exe-
cuting a FAL 00 instruction or by clearing the error from a Programming Device.
08 Low Battery Flag
Turns ON when a CPU Unit battery voltage drops.
09 Cycle Time Over Flag
Turns ON when a cycle time overrun occurs (i.e., when cycle time exceeds 100 ms).
10 to 12 Not used.
13 Always ON Flag
14 Always OFF Flag
MONITOR mode.
PROGRAM mode to MONITOR mode.
IR and LR bit status is maintained when starting or stopping operation.
All outputs turned OFF.
Function
Section 3-3
Page
28
35
147
147
52
2
13
13
505
163
230
502
502
---
---
161
