Inner Board Settings

Word(s) Bit(s)
Error Log Settings (DM 6655)
The following settings are effective after transfer to the PC.
DM 6655 00 to 03 Style
0: Shift after 10 records have been stored
1: Store only first 10 records (no shifting)
2 to F: Do not store records
04 to 07 Not used. Set to 0.
08 to 11 Cycle Time Monitor Enable
0: Detect long cycles as non-fatal errors
1: Do not detect long cycles
12 to 15 Low Battery Error Enable
0: Detect low battery voltage as non-fatal error
1: Do not detect low battery voltage
1-2

Inner Board Settings

1-2-1

Settings for a Serial Communications Board

This section explains the PC Setup settings related to Inner Boards mounted
in Inner Board slots 1 and 2.
Use the settings in DM 6613 and DM 6614 to set the servicing times for a
Serial Communications Board mounted in Inner Board slot 1. (A Serial Com-
munications Board cannot be mounted in slot 2.)
Word Bits
DM 6613 00 to 07 Servicing Time for Serial Communications Board Port 2
(enabled by bits 08 to 15)
00 to 99 (BCD): Sets the percentage of the cycle time used to
service port 2. The servicing time must be between 0.256 ms
and 65.536 ms.
08 to 15 Serial Communications Board Port 2 Servicing Setting
00: Fixed at 5% of the cycle time.
01: Use time setting in bits 00 to 07.
(When the PC is stopped, the servicing time will always be
10 ms.)
DM 6614 00 to 07 Servicing Time for Serial Communications Board Port 1
(enabled by bits 08 to 15)
00 to 99 (BCD): Sets the percentage of the cycle time used to
service port 1. The servicing time must be between 0.256 ms
and 65.536 ms.
08 to 15 Serial Communications Board Port 1 Servicing Setting
00: Fixed at 5% of the cycle time.
01: Use time setting in bits 00 to 07.
(When the PC is stopped, the servicing time will always be
10 ms.)
