Omron CQM1H - PROGRAM Programming Manual page 511

Cycle Time
Code Mnemonic ON execution
time (µs)
62 PRV Built-in High-speed counter 0 or pulse output from an output bit:
82.4
105.7
High-speed counters 1 to 4 on High-speed Counter Board:
115.0
132.0
124.0
142.0
High-speed counters 1 and 2 or pulse output from ports 1 and 2 on Pulse I/O
Board:
206.4
224.4
206.9
230.7
High-speed counters 1 and 2 on Absolute Encoder Interface Board:
203.7
228.0
205.0
228.0
63 CTBL Built-in high-speed counter 0 or pulse output from an output bit:
189.3
210.5
1.18 ms
1.20 ms
1.13 ms
1.14 ms
153.8
174.9
1.14 ms
1.18 ms
981.0
999.0
High-speed counters 1 to 4 on High-speed Counter Board:
152.0
168.0
1.05 ms
1.07 ms
718.0
735.0
152.0
168.0
1.05 ms
1.07 ms
718.0
735.0
486
Conditions
Designating output via word
Designating output via *DM
Designating output via word (reading status)
Designating output via *DM (reading status)
Designating output via word (reading PV)
Designating output via *DM (reading PV)
Designating output via word (reading status)
Designating output via *DM (reading status)
Designating output via word
(reading range comparison results)
Designating output via *DM
(reading range comparison results)
Designating output via word (reading status)
Designating output via *DM (reading status)
Designating output via word
(reading range comparison results)
Designating output via *DM
(reading range comparison results)
Target table with 1 target in words and start
Target table with 1 target in *DM and start
Target table with 16 targets in words and start
Target table with 16 targets in *DM and start
Range table in words and start
Range table in *DM and start
Target table with 1 target in words
Target table with 1 target in *DM
Target table with 16 targets in words
Target table with 16 targets in *DM
Range table in words
Range table in *DM
Target table with 1 target in words and start
Target table with 1 target in *DM and start
Target table with 48 targets in words and start
Target table with 48 targets in *DM and start
Range table in words and start
Range table in *DM and start
Target table with 1 target in words
Target table with 1 target in *DM
Target table with 48 targets in words
Target table with 16/48 targets in *DM
Range table in words
Range table in *DM
Section 7-3
OFF execution
time (µs)
1.875
1.875
