Basic PC Operation and I/O Processes

1-2-5

Settings for an Analog I/O Board

1-3

Basic PC Operation and I/O Processes

1-3-1

Startup Mode

12
The settings in DM 6611 determine the operation of an Analog I/O Board
mounted in Inner Board slot 2. (An Analog I/O Board cannot be mounted in
slot 1.)
Word Bits
DM 6611 00 to 01 Analog Input 1 Input Signal Range
02 to 03 Analog input 2 Input Signal Range
04 to 05 Analog input 3 Input Signal Range
06 to 07 Analog input 4 Input Signal Range
08
09
10
11
12 to 15 Not used.
This section explains the PC Setup settings related to basic operation and I/O
processes.
The operating mode the PC will start in when power is turned ON can be set
as shown below.
Startup Mode Designation
00: Depends upon Programming Device and DIP switch settings (See table below.)
01: Operating mode last used before power was turned OFF
02: Mode set in bits 00 to 07
Startup Mode (Bits 08 to 15: Valid when bits 00 to 07 are set to 02)
00: PROGRAM mode
01: MONITOR mode
02: RUN mode
Default: Operating mode determined by Programming Device and DIP switch settings
as shown in the table below.
Programming Device
connected at startup
None connected.
Programming Console
connected.
Other Programming
Device connected.
Note 1. In these cases, the CQM1H will not be able to communicate with the con-
nected Programming Device.
Function
Analog Input 1 Usage Selection
Analog Input 2 Usage Selection
Analog Input 3 Usage Selection
Analog Input 4 Usage Selection
Pin 7 of the CPU
Unit's DIP switch
OFF PROGRAM mode
ON RUN mode
OFF Operating mode set on the Program-
ming Console's mode switch
ON PROGRAM mode (See note 1.)
OFF PROGRAM mode (See note 1.)
ON Depends upon the Connecting Cable
being used. (See note 2.)
Section 1-3
Settings
Set the bit status of the
two bits as follows:
00: –10 to +10 V
01: 0 to 10 V
10: 0 to 5 V or
0 to 20 mA
0: Support (use) input.
1: Do not support input.
Set to 0.
15
Bit
DM 6600
Startup mode
0
