Memory Areas
Word Bits
IR 240 00 to 07 Comparison Results: Internal Output Bits
(High-speed
counter 1)
08 to 11 Comparison Results: External Outputs Bits
IR 241 for Outputs 1 to 4
(High-speed
12 Counter Operating Flag
counter 2)
IR 242
13 Comparison Flag
(High-speed
counter 3)
14 PV Overflow/Underflow Flag
IR 243
(High-speed
15 SV Error Flag
counter 4)
AR 05 00 High-speed Counter 1 Reset Bit
01 High-speed Counter 2 Reset Bit
02 High-speed Counter 3 Reset Bit
03 High-speed Counter 4 Reset Bit
04 to 07 Not used.
08 High-speed Counter 1 Comparison Stop Bit 0→1: Starts comparison.
09 High-speed Counter 2 Comparison Stop Bit
10 High-speed Counter 3 Comparison Stop Bit
11 High-speed Counter 4 Comparison Stop Bit
12 High-speed Counter 1 Stop Bit
13 High-speed Counter 2 Stop Bit
14 High-speed Counter 3 Stop Bit
15 High-speed Counter 4 Stop Bit
AR 06 00 External Output 1 Force-set Bit
01 External Output 2 Force-set Bit
02 External Output 3 Force-set Bit
03 External Output 4 Force-set Bit
04 External Output Force-set Enable Bit
05 to 15 Not used.
Pulse I/O Board Flags/Bits
Word Bits
IR 232 00 to 15 High-speed Counter 1 PV (rightmost 4 digits)
IR 233 00 to 15 High-speed Counter 1 PV (leftmost 4 digits)
IR 234 00 to 15 High-speed Counter 2 PV (rightmost 4 digits)
IR 235 00 to 15 High-speed Counter 2 PV (leftmost 4 digits)
IR 236 00 to 15 Port 1 Pulse Output PV (rightmost 4 digits)
IR 237 00 to 15 Port 1 Pulse Output PV (leftmost 4 digits)
IR 238 00 to 15 Port 2 Pulse Output PV (rightmost 4 digits)
IR 239 00 to 15 Port 2 Pulse Output PV (leftmost 4 digits)
IR 240 to IR 243 00 to 15 Not used.
Absolute Encoder Interface Board Flags/Bits
Word Bits
IR 232 00 to 15 Absolute Encoder High-speed Counter 1 PV (rightmost 4 digits)
IR 233 00 to 15 Absolute Encoder High-speed Counter 1 PV (leftmost 4 digits)
IR 234 00 to 15 Absolute Encoder High-speed Counter 2 PV (rightmost 4 digits)
IR 235 00 to 15 Absolute Encoder High-speed Counter 2 PV (leftmost 4 digits)
IR 236 to IR 243 00 to 15 Not used.
528
Name Function
Contains the bit pattern specified by operand in
CTBL(––) when conditions are satisfied.
Contains the bit pattern specified by operand in
CTBL(––) when conditions are satisfied.
0: Stopped
1: Operating
Indicates whether comparison is in progress.
0: Stopped; 1: Operating
0: Normal
1: Overflow or underflow occurred.
0: Normal
1: SV error occurred.
Phase Z and software reset
0: Phase-Z reset disabled
1: Phase-Z reset enabled
Software reset only
0: Software reset disabled
0→1: Executes software reset
1→0: Stops comparison.
0: Continues operation.
1: Stops operation.
0: No effect on output status
1: Forces output ON
1: Force-setting of outputs 1 to 4 enabled
0: Force-setting of outputs 1 to 4 disabled
Function
Function
