IR Area
3-2-4

Flags/Bits for an Inner Board in Slot 1 (IR 200 to IR 215)

Serial Communications Board Flags/Bits
Word Bits
IR 200 00 Serial Communications Board Hardware Error Flag
01 Port Identification Error Flag (hardware error)
02 Protocol Data Error Flag
03 to 10 Not used.
11 Port 2 Protocol Macro Execution Error Flag
12 Port 1 Protocol Macro Execution Error Flag
13 Port 2 PC Setup Error Flag
14 Port 1 PC Setup Error Flag
15 PC Setup Error Flag
IR 201 00 to 03 Port 1 Error Code
04
05
06
07
08 to 11 Port 2 Error Code
12
13
14
15
IR 202 00 to 07 Port 1 Communicating with PT Flags (Bits 00 to 07 = PTs 0 to 7)
00 to 15
IR 203 00 to 07 Port 2 Communicating with PT Flags (Bits 00 to 07 = PTs 0 to 7)
00 to 15
IR 204 00 Port 1 Tracing Flag
01 Port 2
02 to 05 Not used.
06 Port 1 Echoback Disabled Flag (Only used for modem control in pro-
07 Port 2
08 to 11 Port 1 Protocol Macro Error Code
12 to 15 Port 2
Note When using an Inner Board or Communications Unit, do not write to the read
bits/words (R) specified in the Read/Write column of the following tables. Writ-
ing to these bits/words may produce unexpected results.
Function
0: Normal operation 1: Parity error
3: Overrun error 4: FCS error
6: Checksum error 7: Command error
Communications Error Flag
Transmission Enabled Flag
Reception Completed Flag
Reception Overflow Flag
Sequence Abort Completion Flag
0: Normal operation 1: Parity error
3: Overrun error 4: FCS error
6: Checksum error 7: Command error
Communications Error Flag
Transmission Enabled Flag
Reception Completed Flag
Reception Overflow Flag
Sequence Abort Completion Flag
Repeat Counter PV (00 to FF hexadecimal)
Reception Counter (4-digit BCD)
Repeat Counter PV (00 to FF hexadecimal)
Reception Counter (4-digit BCD)
tocol macro mode. See note.)
0: Normal operation
2: Sequence number error
overflow
4: Protocol data grammar error
2: Framing error
5: Timeout error
2: Framing error
5: Timeout error
1: No protocol macro function
3: Reception data/write area
Section 3-2
Read/ Communications
Write modes
R All modes
R
R Protocol macro
R
R
R
R All modes
R
R
R All modes
R
R Host Link or
No-protocol
R
R
R Protocol macro
R All modes
R
R Host Link or
No-protocol
R
R
R Protocol macro
R NT Link in 1:N
mode
R Protocol macro
R No-protocol
R NT Link in 1:N
mode
R Protocol macro
R No-protocol
R Protocol macro
R
R
R
R
R Protocol macro
R
