Omron CQM1H - PROGRAM Programming Manual page 31

PC Setup
Word(s) Bit(s)
DM 6629 00 to 07 Number of TIMH(15) High-speed Timers to Refresh by Interrupt Refreshing
00 to 15 (BCD; e.g., set 3 for timers 00 to 02)
08 to 15 High-speed Timer Interrupt Refresh Enable
00: 16 timers (setting in bits 00 to 07 disabled)
01: Use setting in 00 to 07
DM 6630 00 to 07 First Input Refresh Word for I/O Interrupt 0: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for I/O Interrupt 0: 00 to 12 (BCD)
DM 6631 00 to 07 First Input Refresh Word for I/O Interrupt 1: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for I/O interrupt 1: 00 to 12 (BCD)
DM 6632 00 to 07 First Input Refresh Word for I/O Interrupt 2: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for I/O Interrupt 2: 00 to 12 (BCD)
DM 6633 00 to 07 First Input Refresh Word for I/O Interrupt 3: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for I/O Interrupt 3: 00 to 12 (BCD)
DM 6634 00 to 07 First Input Refresh Word for High-speed Counter 1: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for High-speed Counter 1: 00 to 12 (BCD)
DM 6635 00 to 07 First Input Refresh Word for High-speed Counter 2: 00 to 11 (BCD)
08 to 15 Number of Input Refresh Words for High-speed Counter 2: 00 to 12 (BCD)
DM 6636 00 to 07 First Input Refresh Word for Interval Timer 0: 00 to 15 (BCD)
08 to 15 Number of Input Refresh Words for Interval Timer 0: 00 to 16 (BCD)
DM 6637 00 to 07 First Input Refresh Word for Interval Timer 1: 00 to 15 (BCD)
08 to 15 Number of Input Refresh Words for Interval Timer 1: 00 to 16 (BCD)
DM 6638 00 to 07 First Input Refresh Word for Interval Timer 2 or High-speed Counter 0:
00 to 15 (BCD)
08 to 15 Number of Input Refresh Words for Interval Timer 2 or High-speed Counter 0:
00 to 16 (BCD)
DM 6639 00 to 07 Output Refresh Method
00: Cyclic; 01: Direct
08 to 15 Number of Digits for DIGITAL SWITCH (DSW(87)) Instruction
00: 4 digits; 01: 8 digits
High-speed Counter Settings (DM 6640 to DM 6644)
The following settings are effective after transfer to the PC the next time operation is started.
Inner Board Slot 1 Settings (See 1-2 Inner Board Settings for details.)
DM 6640 to 00 to 15
DM 6641
DM 6642 00 to 03 High-speed Counter 0 Input Mode
0: Differential phase mode; 4: Incrementing mode
04 to 07 High-speed Counter 0 Reset Mode
0: Phase-Z and software reset; 1: Software reset only
08 to 15 High-speed Counter 0 Enable
00: Don't use high-speed counter 0; 01: Use high-speed counter 0.
DM 6643 to 00 to 15 Inner Board Slot 2 Settings (See 1-2 Inner Board Settings for details.)
DM 6644
6
Function
Section 1-1
Page
15
26
26
26
32, 39
16, 475
16, 427
9
39
9
