IR Area
I/O Words Required by
Dedicated I/O Units
154
Name
Analog Input Unit
Analog Output Units
Power Supply Units
B7A Interface Units
G730 Interface Units
I/O Link Unit
Sensor Units
Optical Fiber
Photoelectric Module
Photoelectric Module with
Separate Amplifier
Proximity Module with
Separate Amplifier
Dummy Module
Remote Console
Temperature Control Units
Linear Sensor Interface
Units
CompoBus/S Master Unit
CompoBus/D I/O Link Unit
Note A total of 5 words are required when the next 4 Modules (E3X-MA11, E3C-
MA11, E2C-MA11, and E39-M11) are mounted.
Model
Input words
(starting from
IR 001)
CQM1-AD041
2 or 4
CQM1-DA021
---
CQM1-IPS01
---
CQM1-IPS02
CQM1-B7A02
---
CQM1-B7A12
1
CQM1-B7A03
---
CQM1-B7A13
2
CQM1-B7A21
1
CQM1-G7M21
2 or 1
CQM1-G7N11
2 or 1
CQM1-G7N01
---
CQM1-LK501
2
CQM1-SEN01
1 (See note.)
E3X-MA11
1
E3C-MA11
1
E2C-MA11
1
E39-M11
1
CQM1-TU001
---
CQM1-TC001
2 or 1
CQM1-TC002
CQM1-TC101
CQM1-TC102
CQM1-TC201
1
CQM1-TC202
1
CQM1-TC203
1
CQM1-TC204
1
CQM1-TC301
1
CQM1-TC302
1
CQM1-TC303
1
CQM1-TC304
1
CQM1-LSE01
1
CQM1-LSE02
1
CQM1-SRM21-V1 4, 2, or 1
CQM1-DRT21
1
Section 3-2
Output words
(starting from
IR 100)
---
2
---
1
---
2
---
1
2 or 1
---
2 or 1
2
---
---
2 or 1
1
1
1
1
1
1
1
1
1
1
4, 2, or 1
1
