Host Link Commands
6-5-22 SV CHANGE 3 –– W%
Command Format
1 0
@ x 10 x 10 W
Node Header
No. code
Response Format
460
Operand, SV (Response)
In "Operand," specify the name that indicates the SV classification. Specify
the name in four characters. In "SV," specify either the word address where
the SV is stored or the constant SV.
Operand
OP1 OP2 OP3
C I O
L R (Space) (Space) LR
H R (Space) (Space) HR
A R (Space) (Space) AR
D M (Space) (Space) DM
*
D M
E M (Space) (Space) EM
E M *
C O N
Note Only the CQM1H-CPU61 CPU Unit has an EM area.
Changes the contents of the second word of the TIM, TIMH(15), TTIM CNT, or
CNTR(12) at the specified program address in the user's program. With this
command, program address can be specified for a program of up to
99,999 steps.
5 4 3 2
% x 10 x 10 x 10 x 10
Program address
(00000 to 99999)
