Omron CQM1H - PROGRAM Programming Manual page 512

Cycle Time
Code Mnemonic ON execution
time (µs)
63 CTBL High-speed counters 1 and 2 or pulse output from ports 1 and 2 on Pulse I/O
Board:
623.6
649.3
7.06/7.84 ms
7.07 ms
2.03 ms
2.05 ms
440.0
466.1
6.90 ms
6.95 ms
1.98 ms
1.99 ms
High-speed counters 1 and 2 on Absolute Encoder Interface Board:
540.8
562.4
5.84 ms
5.92 ms
1.32 ms
1.35 ms
414.8
436.4
5.40 ms
5.42 ms
1.31 ms
1.33 ms
64 SPED Pulse output from an output bit from CPU Unit:
106.6
110.9
132.2
Pulse output from ports 1 and 2 from Pulse I/O Board:
272.1
279.3
288.3
65 PULS Pulse output from an output bit from CPU Unit:
98.1
124.1
Pulse output from ports 1 and 2 from Pulse I/O Board:
303.6
324.3
66 SCL 79.4
135.4
67 BCNT 66.3
36.99 ms
68 BCMP 105.0
107.3
146.1
Conditions
Target table with 1 target in words and start
Target table with 1 target in *DM and start
Target table with 16/48 targets in words and start
Target table with 16/48 targets in *DM and start
Range table in words and start
Range table in *DM and start
Target table with 1 target in words
Target table with 1 target in *DM
Target table with 16/48 targets in words
Target table with 16/48 targets in *DM
Range table in words
Range table in *DM
Target table with 1 target in words and start
Target table with 1 target in *DM and start
Target table with 48 targets in words and start
Target table with 48 targets in *DM and start
Range table in words and start
Range table in *DM and start
Target table with 1 target in words
Target table with 1 target in *DM
Target table with 48 targets in words
Target table with 48 targets in *DM
Range table in words
Range table in *DM
Frequency specified by constant
Frequency specified by word
Frequency specified by *DM
Frequency specified by constant
Frequency specified by word
Frequency specified by *DM
Number of pulses specified by word
Number of pulses specified by *DM
Number of pulses specified by word
Number of pulses specified by *DM
Word designation
*DM designation
Counting a word
Counting 6,656 words via *DM
Comparing constant, results to word
Comparing word, results to word
Comparing *DM, results to *DM
Section 7-3
OFF execution
time (µs)
1.875
1.875
1.875
1.875
1.875
1.875
487
